Higher-power OEM programmes need a stack that fits both the electrical target and the chosen system architecture. The SydroPOWER Stack™ MZ163-M4H offers a liquid-cooled PEM platform for developers seeking increased output within the M4 range.

The M4 High stack is specified at 163 kW nominal and 198 kW peak output. Its dimensions are 558 × 473 × 148 mm, with a maximum operating temperature of 95°C and a stated cold-start capability of −30°C. Nominal and peak values describe stack performance and should be distinguished from the finished system’s net output.

The platform supports system integrators and vehicle OEMs that want to determine their own balance-of-plant, thermal management, control strategy and power-electronics arrangement. It provides a higher-output M4 option for programmes where these surrounding systems form part of the customer’s engineering scope.

Discuss your continuous power requirement, transient demand and integration envelope with Sydrogen. An application review can establish the stack interfaces, auxiliary requirements and validation plan needed to develop the complete system.
